Automatic Cashew Peeling Machine
Automatic dry-peeling at volume
The fully automatic configuration of TTQ dry peeling — continuous air-and-friction peeling with automatic recirculation for high-volume lines.
The Automatic Cashew Peeling Machine is the fully automated configuration of TTQ’s dry peeler: kernels are continuously fed, dry-peeled by air and soft friction, and un-peeled kernels are automatically recirculated for a clean finish with minimal labour. It suits high-volume lines needing a consistent 80–90% first-pass peel. For the full method and specifications, see the main cashew peeling machine page.
Technical specifications
| Function | Fully automatic dry peeling |
|---|---|
| Method | Compressed air + soft rollers |
| First-pass peel rate | ~80–90% |
| Recirculation | Automatic |
| Throughput | 300–600 kg/hr |
| Control | PLC |
| Build | Stainless contact parts, food-safe |
Figures are typical and configurable — we confirm exact specifications against your capacity and grade targets.
Built for yield & uptime
Automatic recirculation
Un-peeled kernels loop back on their own for a clean finish without hand-work.
Dry — no water
Air-and-friction peeling protects colour, flavour and shelf life.
Protects whole grades
Gentle handling keeps W180–W450 kernels intact for top export prices.
80–90% first pass
High first-pass rate cuts labour and speeds the line to grading.
Model & capacity comparison
Every model TTQ builds for this stage, side by side. Pick by throughput and footprint — each links straight to a quote.
Peeling machines — models
Dry testa (skin) removal by air and gentle friction. Add heads to scale throughput while protecting whole W-grade kernels.
| Model | Capacity | Power | Footprint (L×W×H) | Crew | Ref | Quote |
|---|---|---|---|---|---|---|
| 1-Head | 120–180 kg/h | 5 HP (3.7 kW) | 8.5 × 1.0 × 2.6 m | 1 | TTQ-PEL-01 | Quote → |
| 2-Head | 240–300 kg/h | 5 HP (3.7 kW) | 8.5 × 1.0 × 2.6 m | 1 | TTQ-PEL-02 | Quote → |
| 3-Head | 360–420 kg/h | 5 HP (3.7 kW) | 8.5 × 1.0 × 2.6 m | 1 | TTQ-PEL-03 | Quote → |
| 4-Head | 420–480 kg/h | 5 HP (3.7 kW) | 8.5 × 1.0 × 2.6 m | 1 | TTQ-PEL-04 | Quote → |
Specifications are indicative and configurable; TTQ confirms exact figures against your capacity, grade targets and factory layout. Model codes shown are TTQ quotation references.
Where it fits in the process
The automatic peeler occupies the peeling stage — dried, conditioned kernels feed in; clean peeled kernels move on to grading and colour sorting.
Automatic Cashew Peeling Machine — FAQ
How is this different from the standard peeling machine?
Is it still dry peeling?
What peel rate can I expect?
