Automatic Cashew Shelling Machine
Fully automatic, minimal hands
The fully automatic configuration of the TTQ shelling machine — auto-fed, multi-head cutting with minimal operator involvement for high-volume lines.
The Automatic Cashew Shelling Machine is the fully automated configuration of TTQ’s shelling / cutting system: nuts are auto-fed to multi-head cutting stations, shelled and separated with minimal manual handling. It targets high-volume plants that need consistent 1,000–1,200 kg/hr throughput with low labour. For the full range of head configurations, capacities and specifications, see the main cashew nut shelling machine page.
Technical specifications
| Function | Fully automatic shelling |
|---|---|
| Throughput | Up to ~1,200 kg/hr |
| Feed | Automatic nut feed & separation |
| Heads | Multi-head (8–16) |
| Air supply | Clean compressed air |
| Control | PLC |
| Build | Steel frame, hardened blades |
Figures are typical and configurable — we confirm exact specifications against your capacity and grade targets.
Built for yield & uptime
Up to 1,200 kg/hr
Auto-fed multi-head cutting delivers full-line capacity from one machine.
Automatic feed
Nuts are fed, shelled and separated automatically — minimal operator involvement.
Low labour
Designed for high-volume plants that need throughput without added headcount.
Built to run for years
Hardened blades and a heavy steel frame stand up to continuous three-shift production.
Model & capacity comparison
Every model TTQ builds for this stage, side by side. Pick by throughput and footprint — each links straight to a quote.
Shelling processing lines — models
Complete shelling lines (cutter + sieving + separation) from compact single-machine setups to 1,200 kg/h multi-machine lines.
| Model | Capacity | Power | Footprint (L×W×H) | Crew | Ref | Quote |
|---|---|---|---|---|---|---|
| 4-knife (compact) | 230 kg/h (Size A) | 3.5 HP (2.6 kW), 3-phase 380V | 4.0 × 1.5 × 1.8 m | — | TTQ-SHL-08 | Quote → |
| 4-knife + conveyor | 230 kg/h (Size A) | 4 HP (3 kW), 3-phase 380V | 4.0 × 4.0 × 1.8 m | — | TTQ-SHL-09 | Quote → |
| 6-knife + sieving | 180–210 kg/h | 8 HP (6 kW) | 4 × 4 × 3 m | 2 | TTQ-SHL-06 | Quote → |
| 8-knife + sieving | 240–280 kg/h | 8 HP (6 kW) | 4 × 4 × 3 m | 2 | TTQ-SHL-07 | Quote → |
| 10-knife + sieving | 400–500 kg/h (Size A) | 8 HP (6 kW) | 4 × 4 × 3 m | 2 | TTQ-SHL-10 | Quote → |
| 10-head line | 350 kg/h (Size A) | 12.25 HP (9.2 kW) | 9.0 × 2.2 × 2.2 m | 2 | TTQ-SHL-15 | Quote → |
| 16-head line | 560 kg/h (Size A) | 13.25 HP (9.94 kW) | 9.0 × 2.2 × 2.2 m | 2 | TTQ-SHL-16 | Quote → |
| 16-knife | 700 kg/h (Size A) | 8 HP (6 kW) | 4 × 4 × 3 m | 2 | TTQ-SHL-11 | Quote → |
| 2×10-knife (auto) | 800–900 kg/h (Size A) | 8 HP (6 kW) | 4 × 4 × 3 m | 2 | TTQ-SHL-12 | Quote → |
| 4×8-knife line | 1,000–1,200 kg/h (Size A) | 21.5 HP (16 kW) | 12 × 5.5 × 3 m | 4 | TTQ-SHL-13 | Quote → |
| 4×10-knife line | 1,000–1,200 kg/h (Size A) | 23 HP (17.25 kW) | 12 × 5.5 × 3 m | 4 | TTQ-SHL-14 | Quote → |
Specifications are indicative and configurable; TTQ confirms exact figures against your capacity, grade targets and factory layout. Model codes shown are TTQ quotation references.
Where it fits in the process
The automatic shelling machine occupies the same core cutting stage — graded, steamed nuts feed in; shelled kernels move on to drying and the shell to the burner.
Automatic Cashew Shelling Machine — FAQ
How is this different from the standard shelling machine?
What throughput does it reach?
Does it need compressed air?
