Cashew Vacuum Packing Machine
Nitrogen-flush, export shelf life
Vacuum and nitrogen-flush packing lines that seal graded kernels into tins or pouches for long, export-ready shelf life.
The TTQ Cashew Vacuum Packing Machine seals graded kernels under vacuum with a nitrogen flush, removing oxygen so cashews stay fresh, crisp and rancidity-free through long export shipping. It packs the industry-standard formats — 10 kg vacuum tins and blocks, and retail pouches — at typical rates of 2–6 packs per minute depending on format. Nitrogen flushing gives cashew kernels a shelf life of up to 12 months, which is what makes container-load export viable.
Technical specifications
| Function | Vacuum + nitrogen-flush sealing |
|---|---|
| Formats | 10 kg tins/blocks, retail pouches |
| Rate | 2–6 packs/min (format-dependent) |
| Gas | Food-grade nitrogen flush |
| Shelf life | Up to ~12 months |
| Drive | 1.5–3 kW + vacuum pump |
| Control | Semi / fully automatic (PLC) |
| Build | Stainless food-contact surfaces |
Figures are typical and configurable — we confirm exact specifications against your capacity and grade targets.
Built for yield & uptime
Export-ready formats
Seals the standard 10 kg vacuum tins and blocks plus retail pouches from one line.
Nitrogen-flush freshness
Displacing oxygen with N₂ keeps kernels crisp and prevents rancidity in transit.
Up to 12-month shelf life
Long, stable shelf life is what makes full-container export shipping viable.
Semi or fully automatic
Scale from an operator-fed sealer to an automatic packing line as volume grows.
Model & capacity comparison
Every model TTQ builds for this stage, side by side. Pick by throughput and footprint — each links straight to a quote.
Packing & metal detection — models
Kernel cleaning, weighing, vacuum/nitrogen sealing and metal detection for export-ready packs.
| Model | Capacity | Power | Footprint (L×W×H) | Cycle | Crew | Ref | Quote |
|---|---|---|---|---|---|---|---|
| Kernel sorting line | 1,000–1,500 kg/h | 0.5 HP (0.4 kW), 3-phase 380V | 1.2 × 1.2 × 1.1 m | — | 1 | TTQ-PCK-01 | Quote → |
| Auto weigh + vacuum | 50–70 packs/h | 1-phase 220V | 1.5 × 2.0 × 1.2 m | 45 s aspiration | 2 | TTQ-PCK-02 | Quote → |
| Full vacuum line | 50–70 packs/h | — | — | — | 8 | TTQ-PCK-03 | Quote → |
| Vacuum packer | — | 3 HP (2.2 kW), 3-phase 380V | 1.5 × 2.0 × 1.2 m | 45 s aspiration | 2 | TTQ-PCK-10 | Quote → |
| Tin vacuum packer | — | 1 HP (0.75 kW), 3-phase 380V | 800 × 600 × 600 mm | — | 1 | TTQ-PCK-11 | Quote → |
| Metal detector | — | 2 HP (1.5 kW) | — | — | — | TTQ-PCK-12 | Quote → |
Specifications are indicative and configurable; TTQ confirms exact figures against your capacity, grade targets and factory layout. Model codes shown are TTQ quotation references.
Where it fits in the process
Packing is the final stage. Graded, colour-sorted kernels arrive here and leave as sealed, labelled, export-ready lots — ready for the container.
Cashew Vacuum Packing Machine — FAQ
Why vacuum-pack cashews with nitrogen?
What pack sizes does the machine handle?
Is the packing line automatic?
