Automatic Raw Cashew Nut Grading Machine
Size before you shell
An automatic calibrating grader that sorts raw cashew nuts into uniform size classes, so every nut cracks the same way in the shelling machine.
The TTQ Raw Cashew Nut Grading Machine sorts unshelled raw nuts into consistent size grades using calibrated rotating drums or vibrating sieves. Uniform sizing is the single biggest factor in shelling yield: when every nut in a batch is the same size, the cutting blades can be set precisely, cutting breakage and raising whole-kernel output. It typically grades 500–2,000 kg/hr and feeds directly into steaming and shelling.
Technical specifications
| Function | Calibrated sizing of raw (in-shell) nuts |
|---|---|
| Throughput | 500–2,000 kg/hr (model-dependent) |
| Size grades | 6–8 calibrated classes |
| Drive | 1.5–3 kW geared motor |
| Screens | Interchangeable drum / sieve decks |
| Control | Manual or PLC line integration |
| Build | Powder-coated steel, food-safe contact parts |
Figures are typical and configurable — we confirm exact specifications against your capacity and grade targets.
Built for yield & uptime
Precise size calibration
Interchangeable drums separate nuts into 6–8 tight size bands for accurate blade settings downstream.
Higher shelling yield
Uniform nuts mean fewer mis-cuts — more whole W-grade kernels and fewer broken splits.
Line-ready automation
Runs standalone or feeds the steamer and shelling machine automatically as part of a PLC line.
Low-maintenance build
Sealed bearings and a simple drum drive keep uptime high and service intervals long.
Model & capacity comparison
Every model TTQ builds for this stage, side by side. Pick by throughput and footprint — each links straight to a quote.
Raw cashew size-grading — models & lines
Rotary size sorters (by drum length) and complete calibration lines. Larger units sort more raw nuts per hour for even shelling.
| Model | Capacity | Power | Footprint (L×W×H) | Cycle | Crew | Ref | Quote |
|---|---|---|---|---|---|---|---|
| 3 m sorter | 300–500 kg/h | 1.5 HP (1.1 kW), 3-phase 380V | 6.0 × 2.0 × 2.5 m | — | 1 | TTQ-CAL-01 | Quote → |
| 6 m sorter | 800–1,000 kg/h | 2.5 HP (1.9 kW), 3-phase 380V | 10.0 × 2.0 × 2.5 m | — | 1 | TTQ-CAL-02 | Quote → |
| 9 m sorter | 1,500–1,700 kg/h | 3.5 HP (2.62 kW), 3-phase 380V | 14.0 × 2.0 × 2.5 m | — | 1 | TTQ-CAL-03 | Quote → |
| 12 m sorter | 1,800–2,000 kg/h | 4.0 HP (3.0 kW), 3-phase 380V | 16.0 × 2.0 × 2.5 m | — | 1 | TTQ-CAL-07 | Quote → |
| 5 T line | 5 tonnes/batch | 0.5 HP (0.4 kW), 3-phase 380V | 2.0 × 1.2 × 1.2 m | 35–45 min/batch | — | TTQ-CAL-04 | Quote → |
| 15–20 T line | 15–20 tonnes/batch | 1.0 HP (0.75 kW), 3-phase 380V | 2.5 × 1.6 × 1.2 m | 30–35 min/batch | — | TTQ-CAL-05 | Quote → |
| 30–35 T line | 30–35 tonnes/batch | 1.0 HP (0.75 kW), 3-phase 380V | 2.5 × 1.6 × 1.2 m | 30–35 min/batch | — | TTQ-CAL-06 | Quote → |
Specifications are indicative and configurable; TTQ confirms exact figures against your capacity, grade targets and factory layout. Model codes shown are TTQ quotation references.
Where it fits in the process
Grading is the first stage on the line. Raw nuts arrive here straight from drying or storage; the sized output flows into the steaming machine and then to shelling.
Automatic Raw Cashew Nut Grading Machine — FAQ
Why grade raw cashew nuts before shelling?
How many size grades does the machine produce?
What capacity is available?
Get a quote on the Automatic Raw Cashew Nut Grading Machine
Tell us your target capacity and grades. We'll come back with the right configuration, a layout and a costed proposal.
