Cashew Grading & Sorting Machine
W180 to W450, sorted by size and colour
Kernel grading and optical colour-sorting machines that separate peeled cashews into export grades — by size (W180–W450) and by colour class.
The TTQ Cashew Grading Machine sorts peeled kernels into the standard export grades — whole white grades from W180 to W450, plus scorched, splits, butts and pieces — by size and shape. Paired with an optical colour sorter, it also separates kernels by colour to meet white-grade specifications automatically. Consistent grading is what lets a processor sell to export specification and price each grade correctly; the machine typically handles 300–1,000 kg/hr.
Technical specifications
| Function | Grades kernels by size, shape & colour |
|---|---|
| Size grades | W180–W450, splits, butts, pieces |
| Colour sorting | Optical (CCD) sorter option |
| Throughput | 300–1,000 kg/hr |
| Grading | Vibratory decks + graded sieves |
| Air supply | For colour-sorter ejectors |
| Control | Manual grading / PLC + optical |
| Build | Stainless food-contact surfaces |
Figures are typical and configurable — we confirm exact specifications against your capacity and grade targets.
Built for yield & uptime
Full W-grade range
Calibrated decks separate whole kernels into W180 through W450 export classes.
Optical colour sorting
A CCD colour sorter removes scorched and off-white kernels to hold white-grade specs.
Grade to export spec
Repeatable, machine-set grading lets you price and ship each class correctly.
Protects premium grades
Gentle handling keeps whole kernels whole through the grading stage.
Model & capacity comparison
Every model TTQ builds for this stage, side by side. Pick by throughput and footprint — each links straight to a quote.
Kernel grading / classification — models
Roller classifiers that sort peeled kernels into W-grades by size. More axes (rollers) = higher throughput.
| Model | Capacity | Power | Footprint (L×W×H) | Crew | Ref | Quote |
|---|---|---|---|---|---|---|
| 12-axis | 150–180 kg/h | 1 HP (0.75 kW) | 7.0 × 1.5 × 2.5 m | 1 | TTQ-GRD-01 | Quote → |
| 18-axis | 210–270 kg/h | 1.5 HP (1.1 kW), 3-phase 380V | 7.0 × 1.5 × 2.5 m | 1 | TTQ-GRD-02 | Quote → |
| 24-axis | 280–360 kg/h | 1.5 HP (1.1 kW), 3-phase 380V | 7.0 × 1.5 × 2.5 m | 1 | TTQ-GRD-03 | Quote → |
| 36-axis | 420–540 kg/h | 2.5 HP (1.9 kW), 3-phase 380V | 7.0 × 1.5 × 2.5 m | 1 | TTQ-GRD-04 | Quote → |
| Broken-kernel sorter | 150–200 kg/h | 0.5 HP (0.4 kW), 1-phase 220V | 2.2 × 0.8 × 1.2 m | 1 | TTQ-GRD-05 | Quote → |
Optical colour sorters — models
Camera-based sorting that separates kernels by colour class and removes defects at high speed.
Specifications are indicative and configurable; TTQ confirms exact figures against your capacity, grade targets and factory layout. Model codes shown are TTQ quotation references.
Where it fits in the process
Grading and sorting follow peeling and precede vacuum packing. The graded, colour-sorted kernels are what the packing line seals into export-ready lots.
Cashew Grading & Sorting Machine — FAQ
What cashew grades does the machine sort?
Do I need a separate colour sorter?
What is the difference between W240 and W320?
